- For us, customers always come first. Through in‑house innovation, we design our solutions to meet customer needs, building their trust through genuine, high performance and reliable technology backed by our commitment to excellence.
☰
COB technology is revolutionizing the active LED display by making it more robust, with better surface finish and beneficial in adding touch functionality, which was not possible with other active LED displays. Xtreme Media's COB displays further enhance your active LED screen experience with high colour gamut, 16K high-resolution, HRD 10 picture quality & contrast ratio of 20000:1 to 40000:1.
Download BrochureCommon Cathode Technology combined with the usage of special power saving IC and high efficiency PFC (Power Factor Correction) power supplies avoid wastage of power and help save energy.
The LIT Series delivers exceptional true-to-life colour reproduction, capable of rendering billions of shades with remarkable accuracy and consistency. Powered by advanced color calibration and high bit-depth processing, it ensures richer tones, smoother gradients and enhanced color uniformity across the display.
The LIT series LED displays use flip chip COB (Chip-On-Board) technology for RGB color chips. Flip Chip tech improves thermal control, electrical performance, pixel density and color consistency resulting in stable, durable and high-quality LED displays. These finest pixel pitch displays also come with an HDR 10 level display effect.
The LIT Series is engineered to deliver exceptional deep blacks, creating a powerful sense of depth and realism in every frame. With advanced surface technology and superior contrast performance, these LED displays ensure richer color expression, sharper detail and enhanced visual clarity from every viewing angle. Its anti-reflective characteristics minimize glare, enabling distraction-free viewing and consistent vivid imagery. This in turn every visual appear more immersive, dynamic and true to life.
Xtreme Media's Fine Pitch LIT series LED displays offer high contrast ratios of 20000:1 to 40000:1 and higher bit grayscales, which together uplift the colour space in the display and deliver astounding visuals.
The high-end application displays need lower failure chances with efficient and quick recovery. The fine pitch screens are equipped with backup data and power system which reduces the chances of complete failure and screen blackout.
| Model Name | XM LIT-0.78 | XM LIT-0.9 | XM LIT-1.25 | XM LIT-1.56 |
|---|---|---|---|---|
| Pixel pitch (mm) | 0.78 | 0.9 | 1.25 | 1.56 |
| Cabinet dimension (W x H) mm | 600 x 337.5 | 600 x 337.5 | 600 x 337.5 | 600 x 337.5 |
| Weight (kg/m2) | 21 | 21 | 21 | 21 |
| Technology | Common Cathode | Common Cathode | Common Cathode | Common Cathode |
| Maximum brightness (nits) | 600 | 800 | 800 | 800 |
| Contrast ratio | 20000:1 | 40000:1 | 40000:1 | 40000:1 |
| Max power (W/m2) | 340 | 330 | 275 | 250 |
| Refresh rate (Hz) | 3840 | 3840 | 3840 | 3840 |
| Ingress protection | IP60 front / IP50 back | IP60 front / IP50 back | IP60 front / IP50 back | IP60 front / IP50 back |
| Cabinet type | Die-Cast Aluminum | Die-Cast Aluminum | Die-Cast Aluminum | Die-Cast Aluminum |
| Data Processing | 13-19 Bit | 13-19 Bit | 13-19 Bit | 13-19 Bit |
| Certification | CE-EMC, CE-LVD, FCC, BIS | CE-EMC, CE-LVD, FCC, BIS | CE-EMC, CE-LVD, FCC, BIS | CE-EMC, CE-LVD, FCC, BIS |
The world’s first company in the LED display industry to provide a warranty promise that ensures protection of your investment, reputation and peace of mind. We are the only Indian LED display manufacturer to comply with 12 international quality standards.
.webp)
.webp)
.webp)
.webp)
.webp)
*7-year warranty is subject to specific product line or series.
